69HVAC-PRO2
ULTIMA ID™ PRO 2 HVAC REFRIGERANT IDENTIFIER

Product Description

The Ultima ID Pro 2 HVAC/R Refrigerant Analyzer enables fast, accurate testing of refrigerant, reducing the need for costly and time-consuming gas chromatography. Improved accuracy and the ability to test for a wide variety of refrigerants make this an essential tool for pre-screening refrigerant prior to consolidation and reclamation.

Key Features:

  • Oil contamination resistant
  • Fast test results
  • Internal thermal printer
  • Greater accuracy in less time
  • Wide refrigerant range
  • Refrigerant composition breakdown
  • Remote software updates for new refrigerants
  • Vapor or liquid sample analysis
  • 1/4″ Flare sample hose

SPECIFICATIONS:

  • Weight: Less than 10 Lbs.
  • Analyzed Refrigerants: R22, R32, R134a, R404A, R407C, R410a, Hydrocarbons (HC) and Air
  • Identified Refrigerants: R12, R1234yf, R408A, R409A, R417A, R421A, R421B, R422A, R422B, R422C, R427A and Hydrocarbons (HC)
  • Accuracy: +/- 2% of indicated gasses or better
  • Power Requirements: 12 VDC @ 2A via 110/220 VAC Adapter
  • Approvals: CE, UL and CUL
  • User Interface: Graphic display, soft keys, built in printer
  • Sample Gas Extraction: Pressure from cylinder or system
  • Temperature Range: 50 to 120˚F
  • Humidity: 0-95% RH non-condensing
  • Response Time: Less than 3 minutes
  • Test Sample Size: 5 g per test
  • Test Pressure: 50 psi – 500 psi

Also Available:
69HVAC-PRO2EU: with schuko plug

Available Downloads

PDF_downlaod Instructions
PDF_downlaod Flier
