90059-R
1.5 CFM VACUUM PUMP (SINGLE STAGE)

Product Description

THIS ITEM IS NO LONGER AVAILABLE

• High volume fan provides cool air motor and pump
• Vapor discharge/oil fill port, easily removable, contains internal check valve to prevent escape of liquid oil
• Non-slip cushion handle
• Includes T-fitting with 1/4″ flare and 1/2″ acme ports
• Cooling fins to keep temperature cooler during extended motor operation
• Manifold valve isolates pump from the system testing for leaks

SPECIFICATIONS:

• No. of Stages: 1
• Free Air Displacement: 1.5 CFM
• Ultimate Vacuum: 75 Microns
• Pump Motor: 1/6 HP
• Pump Speed: 3450 RPM
• Electrical Specs: 110 V/60 Hz
• Shipping Weight: 16 lbs (7.25 kg)
• Dimensions in cm: 29.5 x 11.5 x 21.5 x 18

* PLEASE NOTE: The micron readings on all vacuum pumps represent optimal laboratory conditions. Field conditions may vary from these readings.

Also Available:
90059-R-220

• No. of Stages: 1
• Free Air Displacement: 35 lit/min, 42 lit/min
• Ultimate Vacuum: 75 Microns
• Pump Motor: 1/6 HP
• Pump Speed: 2850/3450 RPM
• Electrical Specs: 220 V/50 Hz, 220 V/60 Hz
• Shipping Weight: 16 lbs (7.25 kg)
• Dimensions in cm: 29.5 x 11.5 x 21.5 x 18
